Opel Zafira
New Opel Zafira is created for a full life. The perfect combination of spacious interior, style and dynamics.
A car that can take aboard seven will take your family, friends or colleagues to wherever you wish.
The Flex7 system provides ample opportunities for transforming the cabin, allowing you to carry a large amount of cargo, as well as traveling large companies.
The unique Flex7 system, consisting of three rows of seats designed for seven people, has made the number of possible variants of the salon transformation almost uncountable.
Second row seats easy to fold, providing ease of access and downloads. In addition, these seats can be moved in the longitudinal direction, which allows you to make room for extra luggage.
Suffice it to fold them and push them close to the seats of the first row, to form a huge luggage compartment.
The seats of the third row are removed separately, forming a flat floor. The front passenger seat can also be folded when carrying particularly long items.
The new Opel Zafira installed one of four petrol engines.
All of them are made according to the technology ECOTEC and have four valves per cylinder, which inCombined with turbocharging (2.0T engine) and TWINPORT technology (1.6 engine), it was possible to achieve exceptional performance and speed characteristics without additional increase in mass and fuel consumption.
6-speed automatic transmission.
It is installed with the engine 1.9 CDTI, 88 kW (120 hp) or 110 kW (150 hp), improves the convenience of switching speeds and economy. Complemented with features such as ActiveSelect for smooth gear shift, winter program and sport mode.
IDSPlus with a continuous control system (CDC) in the modereal time monitors the dynamic processes of all wheels and continuously changes the stiffness characteristics of the suspension to best match the condition of the pavement and high-speed driving.
Thanks to the availability of this system, you can enjoy exceptionally sharpened handling, confident passage of turns and increased stability on the road.
The button "SportSwitch"Adds a twist to the excellent handling Opel Zafira. This button, along with the sports chassis and the IDSPlus system, is included in the "sports package" and serves to activate the sports mode.
Opel system SAFETEC begins with a mark of 5 stars for a rigid structure of protection of passengers.
In order to achieve minimal damage and the maximum volume of protected space with a strong frontal, side or rear collision, the system was developed on a computer and then tested physically.
Add to this such elements active protection, such as ESP Plus, IDS, ABS with control unit(CBC), active head restraints, Pedal Release System (PRS), front air bag and chest protection for driver and front passenger, automatic flashing alarms, etc.
The system of airbags.
Full-size front and side cushionsprotect the driver and passenger on the front seats. Any car of the model range can be equipped with cushion-curtains, which protect everyone in the cabin. Also, the front passenger seat can be equipped with a child restraint system.
ABS brakes with cornering braking control (CBC).
Anti-lock braking system (Abs) in the Zafira is supplemented by the CBC to maintain confident control over the car when braking on corners.
Auxiliary emergency braking system (EBC).
For emergency braking, an additional valveIncreases brake fluid pressure, allowing you to safely stop the machine. When the ABS is started, the rear brake lights flash rapidly, warning the cars following the danger.
The car is equipped with a system pedestrian protection, which is a special design of the front of the body.
Elements of the front part of the body have a design characteristic of the deformation character, which allows to significantly reduce the degree of injury to pedestrians in road accidents.
To ensure safety and confidence inDriving Interactive Management System (IDS) The Opel Zafira coordinates the operation of various active safety systems, such as anti-lock brakes, side skid anti-roll braking and the vehicle's dynamic stabilization system.
This system is an integral part of the integrated system SAFETEC , which has front and side airbags, as well as inflatable window curtains, which are optional.
Adaptive Light System (AFL), using powerful xenon lamps,is able to adapt to the speed of the car and the angle of rotation of the steering wheel to provide more effective illumination of the road when cornering.
Parking system Park Pilot. Front and rear sensors give a warning sound signal if the driver, parking the car, dangerously approaches the obstacle. The system can be deactivated by pressing the button.
Column with adjustable slope.
In addition to an ergonomically high leverZafira is equipped with a steering column that is adjustable in tilt and height, which increases the comfort of the driver, allowing you to drive in the most comfortable position.
Electronic climate control (ECC).
Choose the ideal temperature for yourself, and the ECC will keep it at a constant level. The system includes a sunlight intensity sensor and (for an additional fee) an air quality sensor.
Twin Audio.
Stereo headphones allow passengers in the rear seats to connect to the audio system of the car and listen to radio programs or CD-recordings regardless of the driver and front passenger.
The control buttons are located at the rear of the center panel, there are separate volume controls for each of the two pairs of headphones.
Portal for mobile phone.
In the factory, Zafira can be equipped withdevice for using most types of mobile phones, including hands-free mode. The stand for the phone is a universal holder with a special telephone adapter.
Starting from systems CD 30 and above, you can control the phone in the same way as information from the ignition block: from the buttons on the steering wheel. AT standard set voice control systems and Bluetooth. The portal is designed to work with mobile phones of the next generation.
Input socket (aux-in) for connecting external devices.
The socket is located on the central panel and allows you to quickly connect any portable devices that have a headphone output, such as an MP 3 player or iPod.
18-inch wheels with light alloy wheels.
The polished silver disc of silvery color with 9 V-shaped spokes and a bell from the brushed aluminum rings further emphasizes the sporty look.
Towing coupling forks.
Zafira can be equipped with coupling forks with removable or rigid ball bearings towing equipment.
Bicycle mounts in the luggage compartment.
To install it, no tools are required. Can carry up to three bikes with removed front wheels.
FlexOganizer partition.
Includes 2 fixing rails and a grid with pockets that are fastened with which large pieces of luggage are attached.
Child seat Opel DUO ISOFIX.
It is recommended for children weighing from 9 to 18 kg. It can be easily mounted on a normal seat with a 3-point safety belt or ISOFIX system. Child seat Opel DUO ISOFIX has a 5-point seat belt.
</ p>
The Flex7 system provides ample opportunities for transforming the cabin, allowing you to carry a large amount of cargo, as well as traveling large companies.
Flex7 system
The unique Flex7 system, consisting of three rows of seats designed for seven people, has made the number of possible variants of the salon transformation almost uncountable.
Second row seats easy to fold, providing ease of access and downloads. In addition, these seats can be moved in the longitudinal direction, which allows you to make room for extra luggage.
Suffice it to fold them and push them close to the seats of the first row, to form a huge luggage compartment.
The seats of the third row are removed separately, forming a flat floor. The front passenger seat can also be folded when carrying particularly long items.
Engine and control
The new Opel Zafira installed one of four petrol engines.
All of them are made according to the technology ECOTEC and have four valves per cylinder, which inCombined with turbocharging (2.0T engine) and TWINPORT technology (1.6 engine), it was possible to achieve exceptional performance and speed characteristics without additional increase in mass and fuel consumption.
6-speed automatic transmission.
It is installed with the engine 1.9 CDTI, 88 kW (120 hp) or 110 kW (150 hp), improves the convenience of switching speeds and economy. Complemented with features such as ActiveSelect for smooth gear shift, winter program and sport mode.
IDSPlus with a continuous control system (CDC) in the modereal time monitors the dynamic processes of all wheels and continuously changes the stiffness characteristics of the suspension to best match the condition of the pavement and high-speed driving.
Thanks to the availability of this system, you can enjoy exceptionally sharpened handling, confident passage of turns and increased stability on the road.
The button "SportSwitch"Adds a twist to the excellent handling Opel Zafira. This button, along with the sports chassis and the IDSPlus system, is included in the "sports package" and serves to activate the sports mode.
Security
Opel system SAFETEC begins with a mark of 5 stars for a rigid structure of protection of passengers.
In order to achieve minimal damage and the maximum volume of protected space with a strong frontal, side or rear collision, the system was developed on a computer and then tested physically.
Add to this such elements active protection, such as ESP Plus, IDS, ABS with control unit(CBC), active head restraints, Pedal Release System (PRS), front air bag and chest protection for driver and front passenger, automatic flashing alarms, etc.
The system of airbags.
Full-size front and side cushionsprotect the driver and passenger on the front seats. Any car of the model range can be equipped with cushion-curtains, which protect everyone in the cabin. Also, the front passenger seat can be equipped with a child restraint system.
ABS brakes with cornering braking control (CBC).
Anti-lock braking system (Abs) in the Zafira is supplemented by the CBC to maintain confident control over the car when braking on corners.
Auxiliary emergency braking system (EBC).
For emergency braking, an additional valveIncreases brake fluid pressure, allowing you to safely stop the machine. When the ABS is started, the rear brake lights flash rapidly, warning the cars following the danger.
The car is equipped with a system pedestrian protection, which is a special design of the front of the body.
Elements of the front part of the body have a design characteristic of the deformation character, which allows to significantly reduce the degree of injury to pedestrians in road accidents.
To ensure safety and confidence inDriving Interactive Management System (IDS) The Opel Zafira coordinates the operation of various active safety systems, such as anti-lock brakes, side skid anti-roll braking and the vehicle's dynamic stabilization system.
This system is an integral part of the integrated system SAFETEC , which has front and side airbags, as well as inflatable window curtains, which are optional.
Comfort
Adaptive Light System (AFL), using powerful xenon lamps,is able to adapt to the speed of the car and the angle of rotation of the steering wheel to provide more effective illumination of the road when cornering.
Parking system Park Pilot. Front and rear sensors give a warning sound signal if the driver, parking the car, dangerously approaches the obstacle. The system can be deactivated by pressing the button.
Column with adjustable slope.
In addition to an ergonomically high leverZafira is equipped with a steering column that is adjustable in tilt and height, which increases the comfort of the driver, allowing you to drive in the most comfortable position.
Electronic climate control (ECC).
Choose the ideal temperature for yourself, and the ECC will keep it at a constant level. The system includes a sunlight intensity sensor and (for an additional fee) an air quality sensor.
Twin Audio.
Stereo headphones allow passengers in the rear seats to connect to the audio system of the car and listen to radio programs or CD-recordings regardless of the driver and front passenger.
The control buttons are located at the rear of the center panel, there are separate volume controls for each of the two pairs of headphones.
Portal for mobile phone.
In the factory, Zafira can be equipped withdevice for using most types of mobile phones, including hands-free mode. The stand for the phone is a universal holder with a special telephone adapter.
Starting from systems CD 30 and above, you can control the phone in the same way as information from the ignition block: from the buttons on the steering wheel. AT standard set voice control systems and Bluetooth. The portal is designed to work with mobile phones of the next generation.
Input socket (aux-in) for connecting external devices.
The socket is located on the central panel and allows you to quickly connect any portable devices that have a headphone output, such as an MP 3 player or iPod.
Functional equipment
18-inch wheels with light alloy wheels.
The polished silver disc of silvery color with 9 V-shaped spokes and a bell from the brushed aluminum rings further emphasizes the sporty look.
Towing coupling forks.
Zafira can be equipped with coupling forks with removable or rigid ball bearings towing equipment.
Bicycle mounts in the luggage compartment.
To install it, no tools are required. Can carry up to three bikes with removed front wheels.
FlexOganizer partition.
Includes 2 fixing rails and a grid with pockets that are fastened with which large pieces of luggage are attached.
Child seat Opel DUO ISOFIX.
It is recommended for children weighing from 9 to 18 kg. It can be easily mounted on a normal seat with a 3-point safety belt or ISOFIX system. Child seat Opel DUO ISOFIX has a 5-point seat belt.
Characteristics of Opel Zafira
| Total information | ||||
| Model | Opel Zafira 1.6 | Opel Zafira 1.8 | Opel Zafira 2.0 Turbo | Opel Zafira 2.2 |
| Year of issue | 2005 ... | 2005 ... | 2005 ... | 2005 ... |
| Body | Compactavan | Compactavan | Compactavan | Compactavan |
| Number of doors / seats | 5 / 5-7 | 5 / 5-7 | 5 / 5-7 | 5 / 5-7 |
| The equipped weight, kg | 1430 | 1505 | 1535 | 1500 |
| Gross vehicle weight, kg | 2075 | 2075 | 2175 | 2135 |
| Maximum speed, km / h | 176 | 197 | 225 | 200 (190) |
| Acceleration from place to 100 km / h, from | 14,3 | 11.5 (12.9) | 9,0 | 10.6 (11.6) |
| Minimum turning radius, m | 5,5 | 5,5 | 5,5 | 5,5 |
| Trunk volume min / max, l | 140/645/1820 | 140/645/1820 | 140/645/1820 | 140/645/1820 |
| Dimensions, mm | ||||
| Length | 4467 | 4467 | 4467 | 4467 |
| Width | 1801 | 1801 | 1801 | 1801 |
| Height | 1635 | 1635 | 1635 | 1635 |
| Wheelbase | 2703 | 2703 | 2703 | 2703 |
| Track front / back | 1488/1510 | 1488/1510 | 1488/1510 | 1488/1510 |
| Ground clearance | 150 | 150 | 150 | 150 |
| Engine | ||||
| A type | Petrol with distributed fuel injection | Petrol with distributed fuel injection | Petrol with distributed fuel injection and turbocharging | Petrol with direct fuel injection |
| Location: | Front crosswise | Front crosswise | Front crosswise | Front crosswise |
| Working volume, cc | 1598 | 1796 | 1998 | 2198 |
| Compression ratio | 10,5 | 10,5 | 8,8 | 12,0 |
| Number and arrangement of cylinders | 4 in a row | 4 in a row | 4 in a row | 4 in a row |
| Diameter of the cylinder x stroke of the piston, mm | 79.0 x 81.5 | 80.5 x 88.2 | 86.0 x 86.0 | 86.0 x 94.6 |
| Number of valves | 16 | 16 | 16 | 16 |
| Power hp at rpm | 105/6000 | 140/6300 | 200/5400 | 150/5600 |
| Maximum torque Nm at rpm | 150/3900 | 175/3800 | 262/4200 | 215/4000 |
| Transmission | ||||
| A type | Mechanical 5-speed | Mechanical 5-speed | Mechanical 6-speed | Mechanical 6-speed |
| Drive unit | Front wheels | Front wheels | Front wheels | Front wheels |
| Suspension | ||||
| Front | Independent, spring type, type McPherson, with stabilizer of lateral stability | Independent, spring type, type McPherson, with stabilizer of lateral stability | Independent, spring type, type McPherson, with stabilizer of lateral stability | Independent, spring type, type McPherson, with stabilizer of lateral stability |
| Rear | Semi-independent, longitudinal levers, helical springs, anti-roll bar | Semi-independent, longitudinal levers, helical springs, anti-roll bar | Semi-independent, longitudinal levers, helical springs, anti-roll bar | Semi-independent, longitudinal levers, helical springs, anti-roll bar |
| Tire size | 205/55 R16 | 205/55 R16 | 225/40 R18 | 205/55 R16 |
| Brakes | ||||
| Front | Disk ventilated | Disk ventilated | Disk ventilated | Disk ventilated |
| Rear | Disk | Disk | Disk | Disk |
| Fuel consumption according to the norms of 93/116 / EEC, l / 100 km | ||||
| City cycle | 9,2 | 9.9 (9.7) | 13,3 | 11.3 (11.6) |
| Country Cycle | 5,9 | 6.0 (5.8) | 7,3 | 6.4 (6.7) |
| Mixed cycle | 7,1 | 7.4 (7.2) | 9,5 | 8.2 (8.5) |
| Fuel | Petrol A-95 | Petrol A-95 | Petrol A-95 | Petrol A-95 |
| Fuel tank capacity, l | 58 | 58 | 58 | 58 |
